AC-10K-1G

1-Gang Proximity Reader with Access Keypad

The AC-10K-1G is a combination 125 kHz Wiegand proximity reader and security keypad. Clamshell cards can be read up to 6” away under ideal conditions. The keypad allows users to enter pin codes for entry, either on their own or in conjunction with a card swipe.

The following card formats are supported when used with AC Nio™ software:

26-Bit	HID 26-bit (Industry Standard)
32-Bit	Kantech, CSN, CSN Type 2
33-Bit	DSX
34-Bit	HID Standard, HID C10001, HID 0009P, Honeywell FS42, HID N10002
35-Bit	XceedID
36-Bit	Keyscan Indala, Verex G-Prox, Continental
37-Bit	XceedID, Fairways, Indala, Honeywell, Interlogix, STid 37-V FS01, Interlogix - XceedID
39-Bit	Kantech XSF
40-Bit	Aiphone 40-bit
48-Bit	HID H2004604
50-Bit	RBH
75-Bit	Common Access Card

System Highlights

AC-10K-1G Specifications

AC Series Supported Card Formats

AC Series Quick Start Guide

AC Series Home Page

Features

No features provided.

Specs

Power Input	Power Input 5~14V DC
Power Draw	Power Draw 50mA typical, 115mA peak
Frequency	Frequency 125 kHz
Certifications	Certifications CSA, FCC, CE, C-Tick
Supported Credentials	Supported Credentials Various; see the list above or the Spec Sheet for details.
UL Listing	UL Listing UL 294
Operating Temp	Operating Temp -40°~149°F (-40°~65°C)
Dimensions	Dimensions 4-5/16" H x 3" W x 11/16" D
