Features
SIP
Peer-to-peer
Backwards Compatible
- SIP 2.0 Compliant
- 802.3af PoE
- Illuminated call button indicator
- IP65 rated, weather resistant (IP65)
- Â 1 contact output
- Â 1 trigger input
Specs
Power Source
PoE (IEEE 802.3af class 0)
Power Draw
3.36 Watts
Audio Codec
G.711 (μ-law, A law), G.722
Protocols
IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, FTP, DHCP, NTP, DNS
Port Security
IEEE 802.1X
Operating Temp
-40° - 140°F (-40° - 60°C)
Ingress Protection
IP65
Impact Protection
IK08
Dimensions
4-¾" H x 4-¾" W
Mounting
Flush mounted with locally available 2-gang box (2-1/2" deep or greater), or surface mount with the SBX-2G/A Stainless Steel surface mount box
