AT-406B/A
Components
Handset-to-Handset System, Charcoal Gray (AT-206B, AT-306B)
Jump to:
Features
- Set includes one AT-206B master and one AT-306B sub station
- Call button on master rings all sub stations
- Power supply or battery powered
- Sub stations(s) ring at master only
- Up to two additional sub stations can be added (AT-306B)
Specs
Communication
Handset (full-duplex)
Wire Type
Master Station to Sub Station: 2-cond., overall shield - use Aiphone #822202
Distance
2-Station Set: 2,300'(22AWG) 5,250'(18AWG)
Master Station to 3rd Sub Station: 1,350'(22AWG) 3,100'(18AWG)
