Diagram
[mkb-info]Tenant stations shown are the GT-1A. The GT-1D tenant stations can also be used and wired in the same manner.[/mkb-info]
Wire Type
Audio Line
20AWG (0.8mm) 2 Conductor Solid Non-Shielded PE Insulated
Power
PS24
PS-2420UL
PT
Power Transformer (Contact electric strike or magnetic lock manufacturer for power requirements)
Wiring Distances
Max. wire distance from a distribution point to any tenant is 980’ (300m).
Max. cumulative wire distance is 8200’ (2500m).
Refer to the GT Series Installation Manual for complete wire distance information.
[mkb-tip]Distribution Point: (GTW-DP) Available in North America. This can be any device that parallels or commons the R1 / R2 connection. (Terminal strip, punch down block, wire nuts, etc.)[/mkb-tip]
